RIPPA RL06 Wheel Loader
The RIPPA RL06 is a compact articulated wheel loader (working weight 1725 kg) powered by a Kubota D1105 three-cylinder water-cooled diesel engine (18.2 kW / 3000 rpm) with an electronically controlled high-pressure common rail fuel system, compliant with Euro V and US Stage IV (Tier 4 Stage V) emission standards. Its compact articulated design and shaft transmission deliver strong power, a small steering angle and a tight turning radius with excellent passing ability. With an outstanding maximum unloading height of 2060 mm, off-road tires, an ROPS open cab and easy quick-change of auxiliary tools, the RL06 is ideal for construction, agriculture, municipal and material handling applications.
The RIPPA RL06 is a compact articulated wheel loader (working weight 1725 kg) powered by a Kubota D1105 three-cylinder water-cooled diesel engine (18.2 kW / 3000 rpm) with an electronically controlled high-pressure common rail fuel system, compliant with Euro V and US Stage IV (Tier 4 Stage V) emission standards. Its compact articulated design and shaft transmission deliver strong power, a small steering angle and a tight turning radius with excellent passing ability. With an outstanding maximum unloading height of 2060 mm, off-road tires, an ROPS open cab and easy quick-change of auxiliary tools, the RL06 is ideal for construction, agriculture, municipal and material handling applications.
| Machine working weight | 1725 kg (3802 lb) |
|---|---|
| Bucket capacity | 0.23 m³ (8.1 ft³) |
| Rated load mass (safe load) | 300 kg (661 lb) |
| Maximum load mass | 600 kg (1322 lb) |
| Walking speed | 0 – 8 km/h |
| Gradeability | 25% |
| Ground pressure | 73.72 kPa (10.6 psi) |
| Maximum unloading height | 2060 mm (81.1 in) |
| Maximum loading height | 3380 mm (133.1 in) |
| Maximum unloading distance | 650 mm (25.6 in) |
| Turning radius | 2400 mm (94.5 in) |
| Wheelbase | 840 / 1250 mm |
| Minimum ground clearance | 155 mm (6.1 in) |
