Concrete mixer pump
mixing and conveying functions seamlessly in one concrete pump machine, the concrete mixer pump can be driven by diesel engine or electric motor as your choice. It is widely used for continuously concrete mixing and conveying through high hydraulic pressure along the pipeline in such applications as housing building, bridge or tunnel construction. MINLE brand concrete mixer pump is made with high wear and strong corrosion resistant chrome alloy steel to greatly improve the product performance, and is optimized by the electric proportional control buffering, pressure difference sensing and reversing technology to decrease high pressure oil pump reversing time. Our concrete mixer pump is intelligently controlled to achieve the perfect and high efficient concrete mixing and conveying, it features compact structure, stable concrete pumping, energy saving, high efficiency, flexible movement and easy operation, etc.
mixing and conveying functions seamlessly in one concrete pump machine, the concrete mixer pump can be driven by diesel engine or electric motor as your choice. It is widely used for continuously concrete mixing and conveying through high hydraulic pressure along the pipeline in such applications as housing building, bridge or tunnel construction. MINLE brand concrete mixer pump is made with high wear and strong corrosion resistant chrome alloy steel to greatly improve the product performance, and is optimized by the electric proportional control buffering, pressure difference sensing and reversing technology to decrease high pressure oil pump reversing time. Our concrete mixer pump is intelligently controlled to achieve the perfect and high efficient concrete mixing and conveying, it features compact structure, stable concrete pumping, energy saving, high efficiency, flexible movement and easy operation, etc.
| Max Concrete outlet Pressure (Mpa) | 10 |
|---|---|
| Concrete slump (mm) | 100-200 |
| Aggregate Size (mm) | 30 |
| Power (KW) | 78kw |
| Conveying Cylinder Diameter (mm) | 110/1000 |
| Concrete Cylinder Diameter (mm) | 180/1000 |
| Max Conveying Distance (vertical Height/Horizontal Distance) (m) | 150/500m |
| Pipe Cleaning Mode | Washing |
| Total Weight (kg) | 5250 |
| Discharging capacity | 350L |
| Feeding capacity | 560L |
